5 / 24
AC Master
12/700
AC Master
12/1000
AC Master
12/1500
AC Master
24/700
AC Master
24/1000
AC Master
24/1500
28010700
28011000
28011500
28020700
28021000
28021500
200/220/230/240 V
50/60 Hz (selectable)
200/220/230/240 V
50/60 Hz (selectable)
200/220/230/240 V
50/60 Hz (selectable)
200/220/230/240 V
50/60 Hz (selectable)
200/220/230/240 V
50/60 Hz (selectable)
200/220/230/240 V
50/60 Hz (selectable)
true sine
true sine
true sine
true sine
true sine
true sine
12 V
12 V
12 V
24 V
24 V
24 V
700 W
1000 W
1500 W
700 W
1000 W
1500 W
< 810 W
< 1150 W
< 1730 W
< 810 W
< 1150 W
< 1730 W
< 1230 W
< 1750 W
< 2650 W
< 1230 W
< 1750 W
< 2650 W
plug connection EU
(Schuko) or UK
plug connection EU
(Schuko) or UK
plug connection EU
(Schuko) or UK
plug connection EU
(Schuko) or UK
plug connection EU
(Schuko) or UK
plug connection EU
(Schuko) or UK
91%
92%
93%
93%
94%
94%
LED indication: battery
voltage, load level, status
LED indication: battery
voltage, load level, status
LED indication: battery
voltage, load level, status
LED indication: battery
voltage, load level, status
LED indication: battery
voltage, load level, status
LED indication: battery
voltage, load level, status
200 x 330 x 83 mm
7.9 x 13.0 x 3.3 inch
200 x 372 x 83 mm
7.9 x 14.6 x 3.3 inch
248 x 421 x 83 mm
9.8 x 16.6 x 3.3 inch
200 x 330 x 83 mm
7.9 x 13.0 x 3.3 inch
200 x 372 x 83 mm
7.9 x 14.6 x 3.3 inch
248 x 421 x 83 mm
9.8 x 16.6 x 3.3 inch
2.7 kg
6.0 lb
3.3 kg
7.3 lb
4.2 kg
9.3 lb
2.7 kg
6.0 lb
3.3 kg
7.3 lb
4.2 kg
9.3 lb
potential free alarm
contact
potential free alarm
contact
potential free alarm
contact
potential free alarm
contact
potential free alarm
contact
potential free alarm
contact
CE, E-mark
CE, E-mark
CE, E-mark
CE, E-mark
CE, E-mark
CE, E-mark
INVR-1 remote control
INVR-1 remote control
INVR-1 remote control
INVR-1 remote control
INVR-1 remote control
INVR-1 remote control
high frequency, input and
output fully isolated
high frequency, input and
output fully isolated
high frequency, input and
output fully isolated
high frequency, input and
output fully isolated
high frequency, input and
output fully isolated
high frequency, input and
output fully isolated
10,5 V
10.5 V
10.5 V
21 V
21 V
21 V
12,5 V
12.5 V
12.5 V
25 V
25 V
25 V
16,5 V
16.5 V
16.5 V
33 V
33 V
33 V
14,5 V
14.5 V
14.5 V
29 V
29 V
29 V
70 A
100 A
150 A
35 A
50 A
75 A
< 1.5 A
< 1.5 A
< 1.8 A
< 0.8 A
< 0.8 A
< 0.9 A
< 0.1 A
< 0.1 A
< 0.1 A
< 0.06 A
< 0.05 A
< 0.05 A
100 A
125 A
175 A
50 A
60 A
100 A
25 mm²
35 mm²
50 mm²
16 mm²
16 mm²
25 mm²
< 5 %
< 5 %
< 5 %
< 5 %
< 5 %
< 5 %
all power factors allowed
all power factors allowed all power factors allowed all power factors allowed all power factors allowed
all power factors allowed
-20 °C to 40 °C, derating
power > 40 °C
-4 to 104 ° F
-20 °C to 40 °C, derating
power > 40 °C
-4 to 104 °F
-20 °C to 40 °C, derating
power > 40 °C
-4 to 104 °F
-20 °C to 40 °C, derating
power > 40 °C
-4 to 104 °F
-20 °C to 40 °C, derating
power > 40 °C
-4 to 104 °F
-20 °C to 40 °C, derating
power > 40 °C
-4 to 104 °F
IP21, horizontal wall
mounting
IP21, horizontal wall
mounting
IP21, horizontal wall
mounting
IP21, horizontal wall
mounting
IP21, horizontal wall
mounting
IP21, horizontal wall
mounting
over-temperature,
overload, short circuit,
high/low voltage, reverse
polarity (fuse)
over-temperature,
overload, short circuit,
high/low voltage, reverse
polarity (fuse)
over-temperature,
overload, short circuit,
high/low voltage, reverse
polarity (fuse)
over-temperature,
overload, short circuit,
high/low voltage, reverse
polarity (fuse)
over-temperature,
overload, short circuit,
high/low voltage, reverse
polarity (fuse)
over-temperature,
overload, short circuit,
high/low voltage, reverse
polarity (fuse)
temperature and load
controlled fan
temperature and load
controlled fan
temperature and load
controlled fan
temperature and load
controlled fan
temperature and load
controlled fan
temperature and load
controlled fan
no
no
no
no
no
no
Features
n
Complete range from 300 W to 3500 W.
n
Pure sine wave technology protects
sensitive equipment.
n
Delivers full output at high peak power
under the most demanding conditions.
n
Variable speed fan for quiet operation
at low power.
n
Automatic power saving system for
extended runtime.
n
Compact and lightweight design, saving
valuable installation time.
n
Reliable and safe operation; protected
against over-temperature, overload,
short circuit, high or low battery voltage.
n
Optional remote control for instant
switch off.
n
Convenient plug connection for all
models.
5
