Touch 5
5 Inch touchscreen with built-in WiFi
With a super bright widescreen display and the latest capacitive touchscreen technology,
this compact unit outperforms perfectly in sunlight. It also suits smaller applications where
space is at a premium, or on larger applications as a secondary display.
Touch 5
Product code
80-911-0124-00
GENERAL SPECIFICATIONS
Display Type
5” LED-backlit projected
capacitive widescreen touch
Resolution
800 x 480 pixels
Protection
IPX7, water ingress protection
Operating temperature
-15 °C to +55 °C
(5 °F to 131 °F )
Dimensions, wxhxd
152 x 120 x 57.9 mm
5.98” x 4.72” x 2.28”
Brightness
1200 cd/m
2
Input voltage
12 V DC
Conformity
CE, RCM
Power consumption
900mA @ 13.5 V
Interfaces
NMEA 2000, Micro SD
Specifications
The sleek new Touch 5 adds a compact touchscreen option to your CZone
®
installation. While
offering many of the same features as its bigger brother, the Touch 10, this new display module
adds WiFi connectivity as well as the higher specification IPX7 waterproofing.
The Touch 5 offers
various displays for your
convenience.
Features
n
Easy to use touch interface.
n
Glass dash styling.
n
Super bright widescreen display.
n
Low profile flush mounting.
n
Reduced system cost and complexity,
combines display and Wireless
Interface functionality into one unit.
n
Built-in WiFi connectivity allows direct
connection of iPad for onboad wireless
control and monitoring.
n
Micro SD card slot.
n
NMEA 2000 compatible.
®
